Welded S-cam

TYPE	SD NUMBER	OE KNORR/WABCO	PART NUMBER	M	α	β	F	L1	L2	VEHICLE
Q16/24W	SD96003W	9254241000	100.020.022 A0124200018	M22*1.5VOSS	0	45	7800		187	DAIMLER
	SD96003W07	9254949100	A0194208718		105	-165	7900		37
	SD96003W08	9254949110	A0194208818		-105	165	7900		37
Q20/24W	SD96004WA	9254207500 9254207010 9253207010	1506383 81504106561 81504106615 81504106607 81504106683 81504106427 81504106312 81504106310 81504106348 81504106512 81504106308 81504106309	M16*1.5	0	45	8750		75	DAF MAN NEOPLAN
Q24/24W	SD96005W02	9254919000 9254219000	A0194209118 A0164201418	M22*1.5VOSS	105	-165	7800		37	BENZ
	SD96005W05	9254911050	A0194207718	M22*1.5VOSS	55	180	8000		187	BENZ
	SD96005W13	9254213460	1199429	M16*1.5	-90	-150	8000		112	BENZ DAF VDL BUS
	SD96005WA	9254217500	81504106540 81504109540 81504106620 81504106684	M22*1.5VOSS	0	45	8900		75	MAN
	SD96005WA1	9254217510	81504106551 81504109551 81504106609 81504106619 1523549	M22*1.5VOSS	90	-45	8900		200	MAN NEOPLAN DAF
Q30/24W	SD96008W	9254920010		M16*1.5	0	-105	8000		58	DAIMLER
Q24/30W	SD96001W01	9254914400	A 020 420 0118	M22*1.5VOSS+K1	-105	165	10800		37	BENZ
	SD96001W05	9254215400 9254214500		M22*1.5VOSS	0	45	10800		75
	SD96001W07	9254214520 9254215420	81504106629 81504106633	M22*1.5VOSS	90	-45	10800		200	MAN NEOPLAN
Q27/30W	SD96009W01	9254290610 9254290617	1603234 1270272	M16*1.5	45	135	10600		85	DAF
Q27/30W	SD96009WA	9254290200		M16*1.5	0	180	12000		85叉
Q30/30W	SD96002W	9254221200		M22*1.5VOSS	0	45	10800		75
	SD96002W01	9254922030	A0194208118		-30	-15			37	BENZ
	SD96002W03	9254922090	A0194208518		-55	180			187	BENZ
	SD96002W05	9254929020		M22*1.5VOSS+T	105	-165			37
	SD96002W07	9254324800	5010260189	M16*1.5	0	-135			300
	SD96002W08	9254324810	5010260186		0	45			86
	SD96002WA	9254224340			0	-135	12200		265.5
	SD96002WA1	9254221500	1602676	M22*1.5VOSS	-75	90			50
	SD96002WA3	9254221340		M16*1.5	-30	90			86
Q30/30W3	SD96203L	9254921040		M16*1.5	-35	145	10800		53

Device parameters

FAQ

How to deliver goods to customers?

We usually ship by sea. Jiaxing has an advantageous geographical location and is very close to Shanghai and Ningbo Port, making it very convenient to export by sea. Of course, if the customer’s cargo is urgent, we can also ship it by air.
What is the payment method?

FOB, CIF, DDP or other methods, select specific methods according to the specific situation, we generally pay 30% of the advance payment first, and 70% of the balance due to the bill of lading. Most of our payment methods are T/T, of course, L/C is also acceptable.
How does your company guarantee product quality?

First of all, for any newly developed product, every component must undergo strict inspections such as our performance test and life test. Secondly, during the production process, we will have corresponding inspections after each process. For the final product, the air tightness is 100% fully inspected; Then, we have advanced and complete testing equipment in the industry: universal tensile testing machine, high and low temperature tester, static characteristic tester, life tester, water tightness test, coating tester, hardness tester, salt spray tester, vibration test Instrument, spring life tester, etc. Ensure a full range of testing requirements.
What are the main applications of your product?

Our products are suitable for all commercial vehicles such as medium and heavy trucks, trailers, buses and heavy-duty construction vehicles. Mainly include automobile trucks, construction machinery, trains and railways, mining machinery, forklifts, agricultural machinery and other industries.
