J-Series Quick Release2.0

PREV：J-Series Regular Release NEXT：J-Series Quick Release

TYPE	SD NUMBER	OE KNORR/WABCO	PART NUMBER	M	α	β	F	L1	M3	VEHICLE
K12/16J2	SD201KJ			M22*1.5VOSS	90	180		158
K16/16J2	SD203KJ			M22*1.5VOSS	90	180		150	M48*2
K12/20J2	SD202KJ		BDW6801220	M22*1.5VOSS	90	180		160	M48*2
K14/20J2	SD204KJ			M16*1.5	90	180		150	M48*2
K16/20J2	SD205KJ	BY9370	BY9370	M16*1.5	90	180		150	M48*2
K18/20J2	SD208KJ	BY9372	BY9372	M16*1.5	90	180		150
K18/20J2	SD208KJ01	BY9369	BY9369	M16*1.5	90	180		190
K14/24J2	SD206KJ			M22*1.5VOSS	90	180		160	M48*2
K16/24J2	SD207KJ			M16*1.5	90	180		160	M48*2
K18/24J2	SD209KJ			M22*1.5VOSS	0	135		190	M48*2
K20/24J2	SD210KJ			M22*1.5VOSS	0	135		216	M48*2
K22/24J2	SD211KJ			M22*1.5VOSS	0	135		160	M48*2
	SD211KJ01	BY9451		M16*1.5	0	135		160	M48*2
	SD211KJ02	BY9460						195
	SD211KJ03	BY9452						160
K24/24J2	SD212KJ			M22*1.5VOSS	0	135		160	M48*2
Long Cylinder:
K14/24JA2	SD271KJN01		BDW6801424	M22*1.5VOSS	0	135	9600	161
K14/24JA2	SD271KJN02	BY9276-K001057	4121 1359	M16*1.5	0	135	9600	160	M48x2
K16/24JA2	SD272KJN01			M22*1.5VOSS	90	-135	9700
	SD272KJN02		77723790	M16*1.5	90	180
	SD272KJN03	BY9331-K014030	41285151 41285152	M16*1.5	0	135			M48x2	IVECO

Device parameters

FAQ

How to deliver goods to customers?

We usually ship by sea. Jiaxing has an advantageous geographical location and is very close to Shanghai and Ningbo Port, making it very convenient to export by sea. Of course, if the customer’s cargo is urgent, we can also ship it by air.
What is the payment method?

FOB, CIF, DDP or other methods, select specific methods according to the specific situation, we generally pay 30% of the advance payment first, and 70% of the balance due to the bill of lading. Most of our payment methods are T/T, of course, L/C is also acceptable.
How does your company guarantee product quality?

First of all, for any newly developed product, every component must undergo strict inspections such as our performance test and life test. Secondly, during the production process, we will have corresponding inspections after each process. For the final product, the air tightness is 100% fully inspected; Then, we have advanced and complete testing equipment in the industry: universal tensile testing machine, high and low temperature tester, static characteristic tester, life tester, water tightness test, coating tester, hardness tester, salt spray tester, vibration test Instrument, spring life tester, etc. Ensure a full range of testing requirements.
What are the main applications of your product?

Our products are suitable for all commercial vehicles such as medium and heavy trucks, trailers, buses and heavy-duty construction vehicles. Mainly include automobile trucks, construction machinery, trains and railways, mining machinery, forklifts, agricultural machinery and other industries.
